Get what you really need
Entirely based on the DINA-DR1 lighting controller, the LITE version comes with limited but expandable features. Because there is no perfect controller for all projects, the DR1 LITE is the “on-demand” answer to the most demanding projects.
Refer to the DINA-DR1 page for more information about the product, the table below shows what is standard and what is optional.
2000 SCENES
20 ZONES
1024+ CHANNELS
DINA-DR1 Lite technical specifications
| GENERAL | |
|---|---|
| Dimensions | 160 x 91 x 62 mm |
| Weight | 317g |
| USB connection | Yes |
| Ethernet connection | Yes |
| Output channels |
1024 (expandable to 6144 with eDMX)
|
| Scalable |
Coming soon
|
| RDM | Yes |
|
LED Pixel output
|
Coming soon
|
| eDMX | Yes |
| DALI |
Coming soon
|
|
Internal memory capacity
|
16 MB
|
|
Micro SD card
|
Yes |
|
Nicolaudie Cloud
|
Optional |
| STAND-ALONE | |
|
Number of scenes
|
2000 |
|
Number of zones
|
20 |
|
Power voltage
|
8-15V DC
|
|
Power connector
|
Screw terminal
|
| TRIGGERING | |
| Ports |
8
|
|
Clock/calendar triggers
|
Yes |
|
RS232
|
Optional |
|
Ethernet integration
|
Yes
|
|
AUDIO
|
Optional
|
|
DALI
|
Coming soon
|
|
Remote control apps
|
iOS/Android
|
| PROGRAMMING SOFTWARE/APP | |
|
ESA2
|
PC/Mac
|
|
ESA Pro 2
|
PC/Mac |
|
Arcolis
|
iOS/Android |
